| Brand | MSD |
|---|---|
| Part type | Distributor |
| Brand | MSD |
| Category | Ignition |
| Color | Red |
| Distributor Cap Included | Yes |
| Distributor Type | Magnetic Pickup |
| Emission Code | 3 |
| Engine | Ford FE Block |
| Gear | Steel |
| Gear Material | Steel Melonized QPQ Coated |
| Grade Type | Performance |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| part type | Distributor |
| Product Type | Distributor |
| Sub Category | Distributor and Magneto |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| UPC / GTIN | 00090127485941 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Advance weight pins are staked and tig welded to the plate
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing
- CNC Machined Billet Aluminum Housing and Billet Aluminum Base
- Mechanical advance assembly can be locked out for crank trigger systems
- Nylon pads ensure smooth operation of the advance weights
- Steel Gear Installed
