| Brand | MSD |
|---|---|
| Part type | Distributor |
| Brand | MSD |
| Category | Ignition |
| Color | Gray |
| Distributor Cap Included | Yes |
| Distributor Type | Magnetic Pickup |
| Emission Code | 3 |
| Grade Type | Performance |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Makes | Volkswagen |
| part type | Distributor |
| Product Type | Distributor |
| Sub Category | Distributor and Magneto |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| UPC / GTIN | 00085132084852 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- CNC machined billet aluminum housing and Dupont Rynite base
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- No CARB Exemption Order Number
- Advance weight pins are staked and tig welded to the plate• Nylon pads ensure smooth operation of the advance weights
- Must be used with an MSD Ignition Control
- Mechanical advance assembly can be locked out for crank trigger systems
- Supplied with bolt down distributor cap and rotor
- Designed as a performance upgrade for VW Type I air cooled engines
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing
