| Brand | Pertronix |
|---|---|
| Part type | Ignition Coil |
| Ballast Resistor Included | No |
| Coil Internal Construction | Epoxy |
| Coil Shape | Square |
| Coil Type | Remote Mount E-Core |
| Coil Wire Attachment | Male/HEI |
| Coil Wire Included | No |
| Color | Black |
| EmissionFullDES | 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions. |
| Finish | Matte |
| Grade Type | Performance |
| Ignition Type | Electronic |
| Maximum Voltage | 50000 |
| Mount Type | Factory |
| Mounting Bracket Included | No |
| Mounting Hardware Included | No |
| Mounting Position | Horizontal |
| Primary Inductance | 2.5 |
| Primary Resistance | 0.32 Ohms |
| Requires External Resistor | No |
| Secondary Resistance | 6800 Ohms |
| Turns Ratio | 110:1 |
| Voltage | 12 |
| UPC / GTIN | 00694342011949 |
- 50,000 volts.
- Ultra low primary resistance values.
- Legal in all 50 states and Canada. (C.A.R.B. E.O. #D-57-21)*
- Limited One Year Warranty.
Description
Our performance ignition modules are direct replacements for popular GM and Ford electronic distributors. These modules provide enhanced high RPM performance and when used with their corresponding Flame-Thrower coil, substantially increase spark plug voltage.
