| Brand | MSD |
|---|---|
| Part type | Ignition Control Module |
| Brand | MSD |
| Category | Ignition |
| Color | Gold |
| Connector Gender | Terminal Strip |
| Connector Quantity | 1 |
| Current Draw | 12 |
| Emission Code | 4 |
| Features | Extreme Cylinder Pressure |
| Grade Type | Race |
| Height | 5.75 in |
| Ignition Type | Performance |
| Length | 8.25 in |
| Maximum RPM | 15,000 |
| Mount Type | Surface Mount |
| Mounting Hardware Included | Yes |
| Primary Voltage | 480 |
| Product Type | Ignition Box |
| Secondary Voltage | 50,000+ |
| Spark Energy (mJ per spark) | 315-345 |
| Spark Series Duration | 20 Degree Crankshaft Rotation |
| Sub Category | Control Modules |
| Terminal Gender | Terminal Strip |
| Terminal Quantity | 14 |
| Voltage Required | 12-18 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Weight and Size | 4.85 lbs., 8.25L x 3.75W x 5.75H |
| Width | 3.75 in |
| UPC / GTIN | 00085132078059 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
- Compatible for 4, 6 and 8-cylinders
- Built-in 2-step rev control
- 12-18 Volts, Negative Ground
- Extreme spark output
- 36 Amps at 12,000 RPM
- Single or dual coil output
- 15,000 RPM with 14.4 Volts
Description
For those that are looking for a dual fire MSD 8, the new 8-Plus is all you need. Our engineers were able to deliver an ignition that is capable of firing two coils at once for those extreme racers using dual plug race setups.
