| Brand | MSD |
|---|---|
| Part type | Ignition Control Module |
| Bluetooth | No |
| Brand | MSD |
| C.A.R.B. EO # | D-40-43 |
| Category | Ignition |
| Color | Black |
| Connector Gender | Female |
| Connector Quantity | 1 |
| Current Draw | 1000 |
| Emission Code | 1 |
| Features | No Rev Limiter |
| Grade Type | Performance |
| Height | 1.825 in |
| Ignition Box Type | Digital |
| Ignition Type | Performance |
| Length | 8 in |
| MAP Sensor | No |
| Maximum RPM | 15,000 |
| Mount Type | Surface Mount |
| Mounting Hardware Included | Yes |
| Primary Voltage | 520-540 |
| Product Type | Digital 6A Ignition Control Box |
| Rev Limiter | No |
| Rotary Dials | No |
| Secondary Voltage | 45,000 |
| Spark Energy (mJ per spark) | 135-145 |
| Sub Category | Control Modules |
| Terminal Gender | Male |
| Terminal Quantity | 12 |
| Voltage Required | 12-15 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| UPC / GTIN | 00085132620135 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
- Tach output wire
- Built-in LED for system checks
- .7 Amp per 1,000 RPM
- 15,000 RPM with 14.4 Volts
- 12-15 Volts, 7 Volt Start
- Smooth idle
- Compatible with 4, 6 or 8 cylinder engines
- Sealed, locking connector
- Full, capacitive discharge ignition power throughout the RPM range
- Easy starts
- Quick throttle response
Description
The Digital 6A is a microprocessor controlled, capacitive discharge ignition that multi sparks up to 3,000 RPM providing easy starts, a clean, smooth idle and quick throttle response by optimizing your engines efficiency. Above 3,000 RPM, a single spark stays lit for up to 20⁰ of crankshaft rotation ensuring a complete burn of the air / fuel mixture in every cylinder.
