| Brand | MSD |
|---|---|
| Part type | Ignition Control Module |
| Brand | MSD |
| Category | Ignition |
| Color | Black |
| Connector Gender | Male Female |
| Connector Quantity | 4 |
| Current Draw | 1000 |
| Emission Code | 4 |
| Grade Type | Race |
| Height | 4.3 in |
| Ignition Type | Performance |
| Length | 10.8 in |
| Maximum RPM | 15,000 RPM / 10,000 RPM at Full Power |
| Mount Type | Surface Mount |
| Mounting Hardware Included | Yes |
| Operating Voltage | 12-28 |
| Primary Voltage | 330-550 |
| Product Type | Ignition Box |
| Secondary Voltage | 50,000 |
| Spark Energy (mJ per spark) | 250-680 |
| Sub Category | Control Modules |
| Terminal Gender | Male Female |
| Terminal Quantity | 16 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Width | 7.4 in |
| UPC / GTIN | 00090127130674 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
- Operates between 12- 28V
- Diagnostic LED detects the presence of faults
- Direct plug-in to MSD Power Grid Controller PN7730
- Spark current sense and recording for each firing
- On-the-fly Power Output selection wire
- Compatible with 8/6/4 cylinder engines
- Minimum starting voltage 6-volts
- Reverse battery protection
- 3 Amps per 1,000 RPM @ 16 Volts and 600 mJ
- Spark duration of greater than 250 microseconds
- Over 3A peak spark current when used with the recommended ignition coil PN 82612/3
- Internally protected from damage caused by internal over-temperature or open / shorted coil
- Adjustable output energy up to 680 millijoules (mJ)
- Rated for continuous operation at an output of 600 mJ
Description
To further improve efficiency, unused spark energy is recycled back to the ignition capacitor reducing the power drawn from the battery. The Single Channel Pro 600 Ignition provides up to 20% additional spark gap energy and a 40% increase in spark duration over other 600 mJ ignitions available in the market.
